Cikkszám: 0664918772444
Transzmitter
A/V Processor: 8K High Performance Processor
Protocol: Proprietary RTMS 4.0 protocol developed by Accsoon
Video Input: HDMI, 3G SDI
Video Output: HDMI Loop-Out, USB Video Out (to iOS)
SDI Input Format: 1080p: 23.98/24/25/29.97/30/50/59.94/60fps Level A/B
1080i: 50/59.94/60i
HDMI Input Format: 4K (3840*2160): 23.98/24/25/29.97/30/50/59.94/60p
1080p: 23.98/24/25/29.97/30/50/59.94/60p
1080i: 50/59.94/60i
720p: 50/59.94/60p
HDMI Loop-out Format: Identical to the HDMI video input
DC Port: 5.5mmx2.1mm, center positive
DC Voltage: 7.4~16.8V
Battery: Compatible with NP-F550, NP-F750, NP-F970 battery
Power Consumption: 6.5W average *Without powering other devices
Audio: HDMI embedded, SDI embedded
Latency: 1080p 60 < 25ms
4K 60 < 35ms
(Camera latency not included)
Transmission Range: ≥ 2.5 km
(No obstacles, no interference)
Operating Environment Temperature: -10~40℃
Dimensions (Antennas Not Included): 130mm x 95mm x 32 mm
Weight (Antennas Not Included): 322g
Receiver
Video Output: HDMI, 3G SDI
SDI Output Format: 1080p: 23.98/24/25/29.97/30/50/59.94/60fps
Level A
720p: 50/60p
HDMI Output Format: 4K (3840*2160): 23.98/24/25/29.97/30/50/59.94/60fps
1080p: 23.98/24/25/29.97/30/50/59.94/60fps
720p: 50/60p
Power Consumption: 5.0W average
Weight (Antennas Not Included): 320 g
